Đối lưu cưỡng bức bằng turbin quạt
Màn hiển thị số: 2 cái
Điều chỉnh thời gian từ 1 phút đến 99 ngày
Buồng gia nhiệt: 400 x 320 x 250 mm, 32 l
Tải trọng chứa lớn nhất: 60 kg
Giải nhiệt độ: nhiệt độ phòng đến 300°C (min 5°C)
Điện áp/công suất: 230 V / 1.600 W
Trọng lượng tịnh. 48 kg
Kích thước tủ: 585 x 707 x 434 mm
Bảo hành: 12 tháng
- forced air circulation by quiet air turbine, adjustable in 10% steps
- adjustment of pre-heated fresh air admixture by air flap control in 10% steps
- vent connection with restrictor flap
- adaptive multifunctional digital PID-microprocessor controller with high-definition TFT-colour display
- self-diagnostics for fault analysis
- 1 Pt100 sensor DIN class A in 4-wire-circuit
- digital timer adjustable from 1 minute to 99 days
- parameters adjustable on ControlCOCKPIT: temperature (Celsius or Fahrenheit), fan speed, air flap position, programme time, time zones, summertime/wintertime
- SetpointWAIT function - the process time does not start until the set temperature is reached
- resolution of display for setpoint values 0.1°C up to 99.9°C, 0.5°C from 100°C and for actual values 0.1°C (LED)
- calibration facility directly at ControlCOCKPIT for three freely selectable temperature values
- programme stored in case of power failure
- incl. works calibration certificate for +160°C
- adjustable electronic overtemperature monitor and mechanical temperature limiter TB, protection class 1 according to DIN 12 880 to switch off the heating approx. 20°C above nominal temperature
- w x h x d: 585 x 707 x 434 mm
- fully insulated stainless steel door with 2-point locking (compression door lock)
- rear zinc-plated steel
- w x h x d: 400 x 320 x 250 mm, 32 l
- easy-to-clean interior,made of stainless steel,reinforced by deep drawn ribbing with integrated and protected large-area heating on four sides
- 1 stainless steel grid
- Max. loading of chamber: 60 kg
- min.10°C above ambient up to +300°C
- 230 V (+/- 10%), 50/60 Hz / approx. 1.600 W
- 115 V (+/- 10%), 50/60 Hz / approx. 1.600 W
- net weight approx. 48 kg
- gross weight carton approx. 59 kg
- dimensions approx.:
carton w x h x d: 69 x 96 x 66 cm - the appliances must be transported upright
- 8419 8998
- Federal Republic of Germany
- DE 66812464
